A4-70 Hex Standoffs Male-Female 316 Stainless Marine & Machinery Passivated Custom Sizes
Product Details:
| Place of Origin: | China |
| Brand Name: | guanbiao |
| Certification: | ISO9001 |
| Model Number: | Customizable |
Payment & Shipping Terms:
| Minimum Order Quantity: | 50000 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plastic bag + carton + pallet |
| Delivery Time: | 15-20 work days |
| Payment Terms: | T/T |
| Supply Ability: | 5000000 |
|
Detail Information |
|||
| Dia: | M4-M12, Customizable | Hex Size: | HEX4.75 |
|---|---|---|---|
| Target Market: | All Over The World | Finish: | Passivated (std) / Electropolished (opt) |
| Size: | Various Sizes Available | Material: | Stainless Steel |
| Thread Diameter: | Varied | Use: | Industrial Control Panels, Ect. |
| Tolerant: | +/- 0.05mm | Head Style: | Hex |
| Compatibility: | Suitable For Use With Various Materials | Total Length: | 10mm-100mm |
Product Description
A4-70 Hex Standoffs Male-Female 316 Stainless Marine & Machinery Passivated Custom Sizes
Heavy-duty A4 stainless steel hex standoffs. Male-female threads for harsh environments. M4-M12 sizes, 10-100mm lengths. Corrosion-resistant. Passivated/electropolished. Custom threads.
Engineered for extreme conditions, our **A4 Stainless Steel Hex Standoffs** deliver unmatched corrosion resistance in marine, chemical, and industrial environments. The male-female threading allows secure component stacking, while the hexagonal body withstands high torque. Fully passivated for salt water/acid resistance.
TECHNICAL SPECIFICATIONS |
|
| Material | A4-70 Stainless Steel (316) |
| Thread Size | M4, M5, M6, M8, M10, M12 |
| Head Type | Hexagonal (External 6-sided) |
| Total Length (L) | 10mm, 15mm, 20mm, 30mm, 40mm, 50mm, 60mm, 80mm, 100mm |
| Thread Length | Male: 4mm–8mm; Female: Full body depth |
| Head Diameter (AF) | M4=7mm, M6=10mm, M8=13mm, M10=16mm, M12=19mm |
| Drive Type | Wrench/Socket (External hex) |
| Surface Treatment | Passivated (std) / Electropolished (opt) |
| Customization | Custom lengths, thread pitches (e.g., UNF), electropolishing, large diameters |
Primary Uses & Applications:
- Offshore platform equipment
- Chemical processing machinery
- Food-grade conveyor systems (electropolished)
- Coastal infrastructure & solar farms
- High-vibration motor/pump assemblies
How to Use:
1. Apply **anti-seize** to male threads.
2. **Wrench-tighten male end** into base material.
3. **Mount component** onto female threads.
4. **Secure** with stainless screw (not included).
