Hex Standoffs Male-Female Threaded M2-M6 Sizes Brass/Nylon PCB Spacers Custom Lengths

Hex Standoffs Male-Female Threaded M2-M6 Sizes Brass/Nylon PCB Spacers Custom Lengths

Product Details:

Place of Origin: China
Brand Name: guanbiao
Certification: ISO9001
Model Number: Customizable

Payment & Shipping Terms:

Minimum Order Quantity: 50000
Price: Negotiable
Packaging Details: Plastic bag + carton + pallet
Delivery Time: 15-20 work days
Payment Terms: T/T
Supply Ability: 5000000
Get Best Price Contact Now

Detail Information

Samples: Free Samples Single Weight: 0.42g/pcs
Total Length: 5-50mm, Customizable Corrosion Resistance: High
Shape: Hex Specification: ISO
Finish: Passivated (std) / Electropolished (optional) System Of Measurement: Metric
Grade: A2-70 Hex Size: Customizable

Product Description

Hex Standoffs Male-Female Threaded M2-M6 Sizes Brass/Nylon PCB Spacers Custom Lengths

Precision hex standoffs with male/female threads for PCB mounting. Brass (conductive) or nylon (insulating). M2-M6 sizes, 5-50mm lengths. Custom specs. RoHS compliant. Free CAD models.

Optimize electronic assemblies with our **Hex Male-Female Standoffs** – precision-threaded spacers designed for PCB stacking, component spacing, and EMI management. Featuring **male threads on one end and female threads on the other**, these standalone spacers enable secure, tool-friendly installation via their hexagonal body. Choose **conductive brass for grounding** or **insulating nylon for electrical isolation**.

Hex Standoffs Male-Female Threaded M2-M6 Sizes Brass/Nylon PCB Spacers Custom Lengths 0


TECHNICAL SPECIFICATIONS

Material Brass (CZ121), Nylon 6/6 (PA66)
Thread Size M2, M2.5, M3, M4, M5, M6 (e.g., Male M3 × Female M3)
Head Type Hexagonal (External 6-sided)
Total Length (L)  5mm, 6mm, 8mm, 10mm, 12mm, 15mm, 20mm, 25mm, 30mm, 50mm
Thread Length Male: 3mm–5mm (Standard); Female: Full body depth (e.g., 10mm standoff = 10mm threaded depth)
Head Diameter (AF)  M2=4mm, M3=5.5mm, M4=7mm, M5=8mm, M6=10mm
Drive Type Wrench/Socket (No screw slot – external hex only)
Surface Treatment Passivated (std) / Electropolished (optional)
Customization Non-standard lengths, thread combinations (e.g., M3×M4), materials, plating

Hex Standoffs Male-Female Threaded M2-M6 Sizes Brass/Nylon PCB Spacers Custom Lengths 1


Primary Uses & Applications:

   - PCB stacking in servers/RF equipment
   - Creating ground paths (brass) or signal isolation (nylon)
   - Mounting heat sinks, LEDs, or sensors
   - Robotics/drone component spacing
   - Rack-mounted hardware organization

Hex Standoffs Male-Female Threaded M2-M6 Sizes Brass/Nylon PCB Spacers Custom Lengths 2


How to Use:

   1. **Install male end** into chassis/PEM nut using hex tool.
   2. **Stack PCB/component** onto exposed female threads.
   3. **Secure** with machine screw (sold separately).
   ⚡ *For EMI shielding: Ensure brass standoffs contact conductive surfaces.
