Electrophoretic Black Level 10.9 M10x13 Thread Repair Insert For Wheel

Electrophoretic Black Level 10.9 M10x13 Thread Repair Insert For Wheel
Electrophoretic Black Level 10.9 M10x13 Thread Repair Insert For Wheel
Electrophoretic Black Level 10.9 M10x13 Thread Repair Insert For Wheel Electrophoretic Black Level 10.9 M10x13 Thread Repair Insert For Wheel Electrophoretic Black Level 10.9 M10x13 Thread Repair Insert For Wheel Electrophoretic Black Level 10.9 M10x13 Thread Repair Insert For Wheel Electrophoretic Black Level 10.9 M10x13 Thread Repair Insert For Wheel Electrophoretic Black Level 10.9 M10x13 Thread Repair Insert For Wheel

Large Image :  Electrophoretic Black Level 10.9 M10x13 Thread Repair Insert For Wheel

Product Details:
Place of Origin: China
Brand Name: guanbiao
Certification: ISO, GB, BS, DIN, ANSI,JIS
Model Number: M10/M14*13
Payment & Shipping Terms:
Minimum Order Quantity: 50000PCS
Price: USD0.23/PCS
Packaging Details: Plastic bag 1 small box +outer carton +pallets
Delivery Time: 10-15 work days
Payment Terms: T/T
Supply Ability: 10000PCS/day

Electrophoretic Black Level 10.9 M10x13 Thread Repair Insert For Wheel

Description
Material: Alloy Steel 10B21 Production Process: Cold Heading, Cold Forging
Surface Finish/treatment: Electrophoretic Black Tolerant: +/- 0.05mm
Lead Time: 10~15 Working Days Size: M14/M10*13
Single: 5.05g/pcs Hardness Level: 10.9 Level
Groove: One Word
High Light:

Cold Heading Self Threading Inserts

,

Cold Forging Self Threading Inserts

,

Level 10.9 Thread Repair Insert

Self  Thread Protector Level 10.9 M10x13 For Wheel



Self  Thread Protector Level Description:




A thread protector is a plastic or metal cover used to protect threads. They are typically cylindrical in shape and have both an internal and external thread for easy installation and removal. Thread protectors are commonly used to protect the threads of pipes, drill rods, bolts, and other threaded components from damage during transportation, storage, and operation.



Product name: self-tapping thread sleeve, thread protection sleeve
Material: 10B21
Size: M10/M14*13
Outer teeth: M14
Internal teeth: M10
Groove type: cut a word
Groove depth: 4.0mm
Slot width: 3.0mm
Overall length: 13.0mm
Hardness grade: 10.9 level
Surface treatment: Electrophoretic black
Applications: aircraft, wheels, machinery



Self  Thread Protector Level Features:


The features of a thread protector include durability, ease of installation and removal, corrosion resistance, waterproofing, dustproofing, vibration resistance, and protection of threaded components from damage.



Self  Thread Protector Level Applications:


Thread protectors are widely used in industries such as petroleum, natural gas, chemicals, water treatment, aerospace, military, and others to protect the threads of pipes, drill rods, bolts, valves, and other threaded components. They are also used in industrial, construction, mechanical manufacturing, automotive, and other industries that use various threaded connections.





Self Thread Protector Level product detail presentation



Self Threading Thread Protector Level



Self threading Inserts



Threaded protective sleeves 10.9-Grade High-Strength Iron Threaded Sleeves Internal and external braces



Self threading Inserts Factory environmental display



Nuts for household fingerprint locks ; Nuts for household smart locks Manufacturer



Self threading Inserts CNC machining center



Electrophoretic Black Level 10.9 M10x13 Thread Repair Insert For Wheel 3



Self-Threading inserts are an economical, easy-to-use solution for adding a thread to a variety of steel or alov.



Available in standard or flanged configuration, Self-Threading inserts are steel inserts having both an external and internal thread and two slots which provide rapid cutting action. When driven into a cored or drilled hole, the insert cuts its own thread cleanly and evenly.



Friction between the insert and the steel permanently holds it in place after installation.



Self-threading inserts can be installed into steel or alloy materials with a tap wrench or with a drill press and tapping head. No special tooling is required.



All of the above products are produced by our company. Most of them have complete sets of molds or some molds. If you find us, you can make money. Welcome to call or add wechat: +8613423026460



If you intreasting please send email to me :gbscrews@gmail.com
