Security Pin Torx Button Self Tapping Screws Pin Torx Self Tapping Security Screw
Product Details:
| Place of Origin: | China |
| Brand Name: | guanbiao |
| Certification: | ISO, GB, BS, DIN, ANSI,JIS |
| Model Number: | M6*25 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 50000PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plastic bag 1 small box +outer carton +pallets |
| Delivery Time: | 10-15 work days |
| Payment Terms: | T/T |
| Supply Ability: | 10000PCS/day |
|
Detail Information |
|||
| Material: | Stainless Steel | Size: | PA3*15 |
|---|---|---|---|
| Standard: | ISO, GB, BS, DIN, ANSI,JIS, Non-standard | Surface Treatment: | Zn- Plated,Niplated,Passivated,Tin-plated,Sandblast And Anodize ,Polish,Electro |
| Package: | Plastic Bag 1 Small Box +outer Carton +pallets | After-sales Service: | We Will Follow Up Every Customer And Solve All Your Problems Satisfied After Sales |
| Highlight: | Self Tapping Security Pin Torx Screw,Pin-Torx Self Tapping Security Screw,Self Tapping stainless steel security screws |
||
Product Description
Security Pin Torx Button Self-Tapping Screws – Tamper-Proof Fastening Solution
Product Definition
Our Security Pin Torx Button Self-Tapping Screws are high-performance, tamper-resistant fasteners designed for applications where unauthorized removal must be prevented. These screws feature a unique Pin-Torx drive system, requiring a specialized security bit for installation and removal, making them ideal for public infrastructure, automotive, electronics, and medical devices.
The self-tapping design allows for easy installation without pre-drilling, while the stainless steel construction ensures corrosion resistance and long-term durability. The button head provides a low-profile, aesthetically clean finish, making them suitable for both functional and decorative applications.
Product Specifications (Detailed Parameters)
| Parameter | Specification |
|---|---|
| Drive Type | Pin-Torx (Tamper-Resistant Torx with Center Pin) |
| Head Style | Button Head (Low-Profile, Rounded Top) |
| Material | 304 Stainless Steel (A2) / 316 Stainless Steel (A4) |
| Finish | Plain, Electropolished, Black Oxide, PVD Coated |
| Thread Type | Self-Tapping (Sharp Point, Cuts Own Thread) |
| Diameter (Metric) | M3, M4, M5, M6, M8, M10-M20 |
| Diameter (Imperial) | #6, #8, #10, 1/4", 5/16"-5/8" |
| Length Range | 6mm – 300mm (Custom Lengths Available) |
| Tensile Strength | 304: 500-700 MPa / 316: 600-750 MPa |
| Security Level | High (Requires Specialized Pin-Torx Bit for Removal) |
| Standards | DIN 7500 (Self-Tapping Screws), ISO 14588 (Security Fasteners) |
| Certifications | RoHS, REACH, ISO 9001:2015 |
| Custom Options | Laser Marking, Custom Coatings, Non-Standard Sizes |
Key Features & Benefits
✔ Tamper-Proof Security – Pin-Torx drive prevents standard tools from removing the screw.
✔ Self-Tapping Design – Eliminates the need for pre-drilling, reducing installation time.
✔ Corrosion-Resistant – Stainless steel construction ensures longevity in harsh environments.
✔ Low-Profile Aesthetic – Button head design offers a sleek, flush finish.
✔ Wide Compatibility – Suitable for metal, plastic, and composite materials.
Typical Applications
1. Automotive & Transportation
-
Use Cases: EV battery enclosures, dashboard panels, license plate fasteners.
-
Why Our Screws? Prevents theft and vandalism while resisting road salt corrosion.
2. Electronics & IoT Devices
-
Use Cases: Server racks, smart meters, surveillance cameras.
-
Why Our Screws? Ensures device integrity against tampering in public spaces.
3. Public Infrastructure
-
Use Cases: Bus shelters, railway components, streetlight fixtures.
-
Why Our Screws? Deters vandalism and unauthorized access.
4. Medical Equipment
-
Use Cases: MRI machines, surgical devices, pharmaceutical cabinets.
-
Why Our Screws? Hygienic stainless steel, easy sterilization, and secure fastening.
5. Retail & High-Security Fixtures
-
Use Cases: Display cases, ATM machines, luxury store fittings.
-
Why Our Screws? Combines security with a clean, professional appearance.
Future Trends in Security Fasteners
-
Smart Screws: Embedded RFID/NFC chips for tracking tampering attempts.
-
Enhanced Coatings: Self-healing or anti-microbial finishes for specialized industries.
-
3D-Printed Customization: Rapid prototyping for unique security drive designs.
-
Sustainable Materials: Eco-friendly stainless steel with lower carbon footprint.
Why Choose Our Security Pin Torx Screws?
✅ High-Quality Manufacturing – Precision-engineered for reliability.
✅ Custom Solutions – Tailored sizes, materials, and finishes available.
✅ Global Compliance – Meets international security and corrosion standards.
✅ Fast Delivery – Bulk orders supported with OEM/ODM options.
Contact Us Today for a quote – Secure Your Products with Industry-Leading Fasteners
