Torx Drive Machine Screws ISO/ High Security Fasteners/ Batch Orders Guanbiao hardware
Product Details:
| Place of Origin: | China |
| Brand Name: | guanbiao |
| Certification: | ISO9001 |
| Model Number: | T8 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 50000 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plastic bag + carton + pallet |
| Delivery Time: | 15-20 work days |
| Payment Terms: | T/T |
| Supply Ability: | 5000000 |
|
Detail Information |
|||
| Application: | High Security Installations | Drive Style: | Tamper-Resistant Torx (Torx TR / Security Torx) - Pin-in-Recess Design. |
|---|---|---|---|
| Head Diameter: | 14mm | Torx: | T20 |
| Length: | M1-M20 | Production Process: | Cold Heading, Cold Forging |
| Head Type: | Pan Head, Flat Head, Button Head, Truss Head, Etc. | Standard: | ISO, Non-standard |
| Head Shape: | Button | Material: | Stainless Steel |
| Thread Pitch: | 6 | Salt Spray Test: | 200H |
| Thread Length: | Customizable | Corrosion Resistance: | High |
Product Description
Torx Drive Machine Screws ISO/ High Security Fasteners/ Batch Orders Guanbiao hardware
Secure your assets with our premium Tamper-Resistant Torx Screws. Made from hardened steel with corrosion-resistant coatings. Ideal for public fixtures, electronics & security panels.
Enhance security and deter unauthorized access with our premium Tamper-Resistant Torx Screws (commonly known as Torx TR or Security Torx). These specialized fasteners feature a unique pin in the center of the Torx recess, requiring a corresponding driver bit for installation and removal. Designed to prevent tampering using standard tools, they offer a reliable solution for applications demanding increased security and vandal resistance. Our screws combine robust construction with precise engineering for superior performance.
TECHNICAL SPECIFICATIONS |
|
| Material | Carbon Stee, High-Strength Alloy Steel (e.g., SCr435), Stainless Steel(A2 (304), A4 (316)), |
| Drive Type | Tamper-Resistant Torx (Torx TR / Security Torx) - Pin-in-Recess Design |
| Sizes | Available in a wide range (e.g., #2 to 1/4" nominal shank diameters). |
| Lengths | Various lengths to suit diverse applications. |
| Head Styles | Pan head, Flat head, Button head, Truss head |
| Thread Types | Machine screw threads (e.g., UNC, UNF, Metric coarse/fine) |
| Point Type | Sharp point, blunt point, self-drilling point (specify variants). |
Primary Uses & Applications:
Tamper-Resistant Torx screws are essential where security and prevention of unauthorized disassembly are critical. Common applications include:
* Public fixtures (restrooms, signage, benches).
* Electronics enclosures (computers, gaming consoles, kiosks).
* Security panels, access control systems, and alarm boxes.
* Vending machines and coin-operated devices.
* Automotive interiors, trim, and components.
* Playground equipment and public infrastructure.
* Medical devices and equipment housings.
Surface Treatment/Finishes:
Applied for protection and functionality:
* **Zinc Plating:** Electroplated Zinc (Blue/White/Yellow/Black Chromate).
* **Hot-Dip Galvanizing:** Thick coating for severe outdoor environments.
* **Mechanical Zinc Plating:** Good for hydrogen embrittlement-sensitive parts.
* **Cadmium Plating:** (Limited use, environmental/health concerns, often requires exemption).
* **Nickel Plating:** Decorative and corrosion-resistant.
* **Phosphate & Oil:** Good lubricity, paint adhesion, mild corrosion resistance.
* **Black Oxide:** Appearance, mild corrosion resistance, reduced glare.
* **Dacromet / Geomet®:** Advanced corrosion protection, lubricity.
* **Passivation:** For Stainless Steel (essential for maximum corrosion resistance).
* **Anodizing:** For Aluminum screws (color, corrosion resistance).
How to Use:
Proper installation requires the correct Tamper-Resistant Torx driver bit (TR bit) matching the screw size (e.g., TR15 for a T15 TR screw). Insert the bit firmly into the recess, ensuring the pin engages the corresponding hole in the bit. Apply controlled torque using a suitable screwdriver or driver bit in a power tool. Avoid excessive force to prevent damaging the recess or the driver bit. Always select the screw size, material, and coating appropriate for the specific application environment and load requirements.
