Non-standard A4-80 Triple Security Cap Screws For Public Infrastructure Black Oxide Finish Hex Socket Guanbiao Hardware
Product Details:
| Place of Origin: | China |
| Brand Name: | guanbiao |
| Certification: | ISO9001 |
| Model Number: | M6 * 35 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 50000 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plastic bag + carton + pallet |
| Delivery Time: | 15-20 work days |
| Payment Terms: | T/T |
| Supply Ability: | 5000000 |
|
Detail Information |
|||
| Materia: | Stainless Steel A4-70 | Grade: | 18-8 |
|---|---|---|---|
| Production Process: | Cold Heading, Cold Forging | Application: | High Security Installations |
| Finish: | Plain, Black Oxide, Zinc Plated, Etc. | Hexagonal Opposite Length: | M2.0*2.0 |
| Shape: | External Hexagon | Standard: | ISO, Non-standard |
| Installation Method: | Screwdriver, Wrench, Drill | Corrosion Resistance: | Highly Resistant To Rust And Corrosion |
| Thread Length: | Customizable | ||
| Highlight: | Hex Socket Security Cap Screws,Non-standard Security Cap Screws |
||
Product Description
A4-80 Triple Security Cap Screws/ Vandal Proof/ Public Infrastructure/ Hex Socket/ Batch Orders Guanbiao Hardware
Ultimate security A4 stainless steel cap head screws. Three-combination defense: tamper-resistant drive, permanent threadlocker & breakaway head. For utilities, transport & public fixtures. Passivated.
Protect critical infrastructure from vandalism and unauthorized access with our **High-Security Cap Head Hexagon Socket Three Combination Screws**. Engineered for maximum defense, these fasteners integrate **three independent security mechanisms**: 1) A **tamper-resistant pin-in-hex socket drive**, 2) A **permanent, high-strength pre-applied threadlocker**, and 3) A **breakaway/frangible hex head**. Made from corrosion-resistant A4 stainless steel, they provide an unparalleled permanent, vandal-proof solution for public utilities, transportation, and high-security enclosures.
TECHNICAL SPECIFICATIONS |
|
| Material | A4 / 316 Stainless Steel (ISO 3506 Class 80 - **A4-80** for high strength) |
| Drive Type | Hexagon Socket (ISO 4762) **with Central Security Pin** (Tamper-Resistant TR) |
| Head Style | Cylindrical Head (DIN 912 / ISO 4762) |
| Thread Pitch | Metric Coarse (Standard) |
| Strength | Min. Tensile Strength: 800 MPa (A4-80) |
| Sizes | Common: M6, M8, M10, M12, M16 |
| Lengths | Standard & Custom (e.g., 20mm, 25mm, 30mm, 35mm, 40mm, 50mm |
Primary Uses & Applications:
* Utility boxes (electrical, telecom, gas, water).
* Public transportation fixtures (bus stops, rail trackside equipment).
* Traffic signal & control cabinet access panels.
* Bridge & tunnel infrastructure access points.
* Permanent security fencing & gate hardware.
* High-value asset protection (ATMs, vending machines - permanent installs).
Surface Treatment/Finishes:
* **Passivation (Standard):** Critical chemical process to maximize corrosion resistance by removing free iron and enriching the passive chromium oxide layer.
* **Electropolishing (Optional):** Enhances corrosion resistance, provides smoother surface (reduced friction during install), bright finish. Improves cleanability.
How to Use:
1. **Prepare:** Ensure female threads are clean, dry, and compatible (A4 nut/threaded hole recommended). Hole must accommodate full screw length *including* the breakaway head.
2. **Insert Screw:** Use the **specialized TR driver bit** (e.g., TR30 for M10) matching the screw size. Insert the screw into the hole.
3. **Tighten:** Apply torque using a calibrated torque wrench/driver. Tighten to the specified torque value for the size and material.
4. **Breakaway:** Once final torque is reached, **continue applying torque**. The specially designed **hex head will shear off cleanly** just below the top surface, leaving only a smooth, non-grippable cylindrical stud. *The screw is now permanently locked in place.*
5. **Removal:** **Extremely difficult and destructive.** Requires drilling out the screw remnant. Replacement requires re-tapping the hole.
